CFAM800480B0-050TC

5" Raspberry Pi Compatible Touchscreen Display - CFAM800480B0-050TC

5" Raspberry Pi Compatible Touchscreen Display. Model: CFAM800480B0-050TC.Specifications Column Dots 800 px Row Dots 480 px Color Depth 64k bits Overall Width 120.70 mm / 4.752 in Overall Height 93.05 mm / 3.663 in Overall Depth 12.52 mm / 0.493 in Diagonal Dimension 5.01 in Weight 128 g Shape Rectangle Active Area Width 108.00 mm / 4.252 in Active Area Height 64.80 mm / 2.551 in Viewing Width 109.00 mm / 4.291 in Viewing Height 65.80 mm / 2.591 in Dot Pitch Width 0.14 mm / 0.005 in Dot Pitch Height 0.14 mm / 0.005 in Dot Size Width 0.14 mm / 0.005 in Dot Size Height 0.14 mm / 0.005 in Module Connector Type ZIF Pin Count 15 Display Technology TFT Glass Type TFT Polarizer Transmissive View Angle 80° Foreground Color RGB Background Color Dark Backlight Type LED Backlight Color White Supply Voltage for Logic Min: -0.5; Typ: 3.3; Max: 3.96 V Supply Current Min: 90; Typ: 110; Max: 130 mA Standard Interface(s) MIPI DSI Touch Screen Capacitive Operating Temperature -20°C / 70°C / -4°F / 158°F Storage Temperature -30°C / 80°C / -22°F / 176°F Special Characteristics rPi Display DatasheetsProduct datasheet

Add to Cart · $1,111.00

• Shipping calculated at checkout
• No MOQ on standard modules
